TP-Link TL-WA3001 AX3000 Gigabit Wi-Fi 6 Access Point

TP-Link TL-WA3001 AX3000 Gigabit Wi-Fi 6 Access Point

TP-Link TL-WA3001, AX3000 Gigabit Wi-Fi 6 Access Point

Features:

• Gigabit WiFi 6 Speed for 4K Streaming - 3000 Mbps Dual Band WiFi for faster browsing, streamingand downloading, all at the same time.
• Flexible Deployment - Supports Passive PoE to carry electrical power and data simultaneously.
• Multiple Modes - Supports Access Point, Range Extender, Multi-SSID, and Client modes to meet any network needs.
• Boosted Coverage - Four fixed antennas equipped with Beamforming technology extend and concentrate the Wi-Fi signals.
• Captive Portal - Offers a designed portal page for heightened security and marketing.

Specifications:

HARDWARE FEATURES

• Interface :1 Gigabit Port (Supports Passive PoE)
• Button :Power On/Off Button, WPS Button, Reset Button
• External Power Supply :48V/0.5A
• Dimensions ( W x D x H ) :9.4x6.5x1.7 in (240x165x43.6mm)
• Antenna Type :4 Fixed High Performance Antennas

WIRELESS FEATURES

• Wireless Standards :IEEE802.11b/g/n/ax 2.4 GHz, IEEE 802.11a/n/ac/ax 5 GHz
• Frequency :2.4 GHz and 5 GHz
• Signal Rate :2402 Mbps at 5 GHz, 574 Mbps at 2.4 GHz
• Reception Sensitivity :5 GHz:
  11ax HE20 MCS0:-97dBm, 11ac VHT20 MCS9:-73dBm, 11ax HE20 MCS11:-67dBm
  11ax HE40 MCS0:-94dBm, 11ac VHT40 MCS9:-70dBm, 11ax HE40 MCS11:-63dBm
  11ax HE80 MCS0:-91dBm, 11ac VHT80 MCS9:-66dBm, 11ax HE80 MCS11:-60dBm
  11ac VHT160 MCS9:-63dBm, 11ax HE160 MCS11:-58dBm
  2.4 GHz:
  11ac VHT20 MCS0:-97dBm, 11ac VHT20 MCS8:-73dBm, 11ax HE20 MCS11:-65dBm
  11ac VHT40 MCS0:-93dBm, 11ac VHT40 MCS9:-69dBm, 11ax HE40 MCS11:-62dBm
• Transmit Power :FCC: <23dBm(2.4GHz), <22dBm(5GHz)
• Wireless Functions :Enable/Disable Wireless Radio, WMM, Wireless Statistics, Access Control
• Wireless Security :WPA, WPA2, WPA3, WPA/WPA2-Enterprise encryptions

SOFTWARE FEATURES

• Quality of Service :WMM
• Operating Modes :Access Point, Range Extender, Client, Multi-SSID
• System Tools :SNMP, Ping Watchdog
• DHCP :Server, DHCP Client List
• Protocols :IPv4, IPv6

OTHERS

• Certification :FCC, RoHS
• Package Contents :Wireless Access Point TL-WA3001
  Power Adapter
  RJ45 Ethernet Cable
  Quick Installation Guide
  PoE Power Injector
• System Requirements :Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or
  other JavaScript-enabled browser
• Environment :Operating Temperature: 0°C ~ 40°C(32°F ~ 104°F)
  Operating Humidity: 10%~90% non-condensing
